Ceramic Fiber Board
MOQ: 50 daim
Kev piav qhia
Lub zog ntawm ceramic fiber board yog siab dua li ntawm fiber ntau daim pam thiab lub tshuab nqus tsev tsim cov ntaub ntawv, thiab yog tsim rau high-temperature teb uas yuav tsum tau rigidity thiab lub zog ntawm cov khoom. Qhov saum npoo yog tiaj tus, qhov loj me yog qhov tseeb, qhov toughness yog qhov zoo, nws tuaj yeem txiav ntawm qhov xav tau, thiab cov nyhuv txuag hluav taws xob zoo heev. Nws yog ib yam hauv thiab sab nraud thiab muaj kev ua haujlwm zoo thaum tshav kub kub rwb thaiv tsev.
Nta
Ceramic fiber board muaj cov yam ntxwv hauv qab no:
1. Zoo heev thermal stability thiab thermal shock kuj
2. Tsawg tshav kub muaj peev xwm
3. Tsawg thermal conductivity
4. Siab compressive zog
5. Zoo toughness
6. Yooj yim rau txheej txheem thiab nruab
Daim ntawv thov
Ceramic fiber board yog qhov zoo tshaj plaws kev txuag hluav taws xob thiab cov khoom siv hluav taws xob kub rau ntau yam kev lag luam kilns. Nws tuaj yeem siv los ua hauv ob sab phlu, phab ntsa hauv ob sab phlu thiab hauv ob sab phlu rwb thaiv tsev ntawm kilns.
Refractory cib thaub qab ntawm electrolytic txo tank hauv aluminium Hoobkas.
Cov tshuaj tiv thaiv kub siab, phab ntsa hauv ob sab phlu thiab cov khoom siv ntawm cov khoom siv cua sov
Physical And Chemical Indicators
| Khoom & Hom | ST BOD | GC BOD | HA BOD | HZ BOD | |
| Specification Kub (degree) | 1260 | 1260 | 1360 | 1430 | |
| Ua haujlwm kub (degree) | 1100 | 110 | 1200 | 1350 | |
| Qhov ceev (g / cm3) | 280-350 | 280-350 | 280-350 | 280-350 | |
| Permanent linear hloov (%) | -3 (1000 degree) |
-3 (1100 degree) |
-3 (1200 degree) |
-3 (1350 degree) |
|
|
Thermal conductivity (w / mk) |
0.085 (400 degree) | 0.085 (400 degree) | 0.085 (400 degree) | 0.085 (400 degree) | |
| 0.132 (800 degree) | 0.132 (800 degree) | 0.132 (800 degree) | 0.132 (800 degree) | ||
| 0.180 (1000 degree) | 0.180 (1000 degree) | 0.180 (1000 degree) | 0.180 (1000 degree) | ||
| Tensile zog (MPa) | 0.2 | 0.2 | 0.2 | 0.2 | |
|
Tshuaj |
Al2O3 | 38 | 42 | 45 | 39-40 |
| Al2O3 plus SiO2 | 96 | 98 | 99 | – | |
| Al2O3 plus SiO2 plus ZrO2 | – | – | – | 99 | |
| ZrO2 | – | – | – | 15-17 | |
| Fe2O 3 | 1 | 0.5 | 0.5 | 0.2 | |
| Na2O plus K2O | 0.5 | 3 | 0.2 | 0.2 | |
Cim npe nrov: Tuam Tshoj ceramic fiber board manufacturers, lwm tus neeg, Hoobkas
